As a professional high quality Lw26 125a Cam Switch manufacturer, the LW26 series rotary switch, also known as a cam switch, changeover switch, or isolating switch, is a versatile electrical component suitable for various applications including circuit switching, circuit conversion, motor control, and instrument operation. This switch series complies with industry standards such as GB 14048.3, GB 14048.5, and IEC 60947-5-1, ensuring quality, reliability, and safety in electrical systems.
The Lixin LW26 125A Cam Switch is a versatile and reliable electrical component designed for a wide range of applications. With its robust construction and advanced features, this switch offers exceptional performance in controlling electrical circuits. Here's a brief introduction to this product:
The Lixin LW26 125A Cam Switch is engineered to meet the demanding requirements of electrical systems operating at up to 125A current rating. It is suitable for both AC and DC circuits, making it adaptable to various power supply configurations.
Featuring a compact design and precise manufacturing, the LW26 125A Cam Switch ensures easy installation and seamless integration into electrical panels and control systems. Its sturdy construction and high-quality materials guarantee durability and long-term reliability in demanding environments.
This cam switch is equipped with advanced switching mechanisms, allowing for smooth and efficient operation. Whether used for manual control or automated switching applications, it delivers consistent performance and precise control over electrical circuits.
The LW26 125A Cam Switch complies with industry standards and certifications, ensuring safety and reliability in operation. It is designed to withstand high electrical loads and harsh operating conditions, making it suitable for a wide range of industrial and commercial applications.
Key Features:
- Rated current: 125A
- Suitable for AC and DC circuits
- Compact design for easy installation
- Durable construction for long-term reliability
- Advanced switching mechanisms for smooth operation
- Compliance with industry standards and certifications
- Suitable for various industrial and commercial applications
In summary, the Lixin LW26 125A Cam Switch offers exceptional performance, reliability, and versatility, making it an ideal choice for controlling electrical circuits in diverse applications.
Controls way |
trait designation |
Actuator position |
|||
Self-replicating type |
A |
0°30° |
0-45° |
0°-60° |
|
B |
30°-0°30° |
45°0°-45° |
60°0°-60° |
||
X |
60-30=0°30-60° |
||||
Locating type |
C |
0°30° |
0°45° |
0°60° |
|
D |
30°0°30° |
45°0°45° |
60°0°60° |
||
E |
30°0°30°60° |
45°0°45°90° |
60°0*60*120° |
||
F |
60°30°0°30°60° |
90°45°0°45°90° |
60°0°60°120°180° |
||
G |
60°30°0°30°60°90° |
90°45°0°45°90°135° |
120°60°0°60°120°180° |
||
H |
90°60°30°0°30°60°90° |
135°90°45°0°45°90°135° |
|||
90°60°30°0°30°60°90°120° |
135°90°45°0°45°90°135°180° |
||||
J |
120°90°60°30°0°30°60°90°120° |
||||
K |
120°90°60°30°0°30°60°90°120°150° |
||||
L |
150°120°90°60°30°0°30°60°90°120°150° |
||||
M |
150°120°90°60°30°0°30°60°90°120°150°180° |
||||
N |
45° 45° |
30°30° |
|||
P |
90°0°90 |
||||
T |
0*90° |
||||
V |
90°0° |
||||
R |
270°0°90°180° |
||||
orientation Self-replicating type |
Q |
30°0°-30° |
45-0°45° |
||
S |
30°-0°60° |
90°0°-45 |
|||
W |
90-45°0°45-90° |
||||
Z |
120°-90°0⁰-30° |
135°-90°0⁶-45° |
Type specification |
LW26-10 LW26-10G LW26-10X |
LW26-20 LW26-20X LW26-20C |
LW26-25 |
LW26-32 LW26-32F |
LW26-40 LW26-40F |
LW26-63 LW26-63F |
LW26-125 |
LW26-160 |
LW26-250 |
LW26-315 |
Ui V |
660/690 |
660 |
660 |
660 |
660 |
660 |
660 |
660 |
660 |
660 |
Ith A |
10 |
20 |
25 |
32 |
40 |
63 |
125 |
160 |
250 |
315 |
Ue V |
240440 |
24110240440 |
24110240440 |
240440 |
240440 |
240440 |
240440 |
240 440 |
240440 |
240440 |
le |
||||||||||
AC-21A AC-22A A |
1010 |
20 20 |
25 25 |
32 32 |
63 63 |
100 100 |
150 150 |
200200 |
315 315 |
|
AC-23A A |
7.57.5 |
15 15 |
22 22 |
30 30 |
37 37 |
57 57 |
90 90 |
135 135 |
265 265 |
|
AC-3 A |
5.55.5 |
11 11 |
15 15 |
22 22 |
30 30 |
36 36 |
75 75 |
95 95 |
110 110 |
|
AC-4 A |
1.751.75 |
3.5 3.5 |
6.5 6.5 |
11 11 |
15 15 |
30 30 |
55 55 |
95 95 |
||
AC-15 A |
2.51.5 |
5 4 |
8 5 |
14 6 |
||||||
DC-13 A |
12 0.40.4 |
20 0.5 0.5 |
||||||||
Rated control power P |
||||||||||
AC-23A KW |
1.8 3 |
3.7/2.5 7.5/3.7 |
5.5/311/5.5 |
75/415/75 |
185/918.5/9 |
15/1030/18.5 |
30/1545/22 |
37/2275/37 |
75/37132/55 |
|
AC-2 KW |
2.53.7 |
4 7.5 |
5.5 11 |
75 15 |
185 30 |
30 45 |
37 55 |
55 95 |
||
AC-3 KW |
1.52.2 |
3/22 5.5/3 |
4/3 7.5/3.7 |
55/411/5.5 |
15/7.515/7.5 |
11/618.5/11 |
15/7.530/13 |
22/1137/18.5 |
37/2255/30 |
|
AC-4 KW |
0.370.55 |
0.55/0.751.5/1.5 |
1.5/1.13/2.2 |
27/1.555/3 |
55/2475/4 |
6/312/5.5 |
10/415/7.5 |
15/7.525/11 |
The Lixin LW26 125A Cam Switch is a durable and efficient electrical component designed for controlling circuits with ease and precision. With its compact design and high-quality construction, this switch is suitable for a variety of applications in industrial and commercial settings.
Overall Dimensions: The LW26 125A Cam Switch features a compact design, with dimensions tailored to fit seamlessly into electrical panels and control systems. Its precise measurements ensure easy installation and integration into existing setups, optimizing space utilization while maintaining functionality.
Mounting Dimensions: Designed for convenience, the LW26 125A Cam Switch comes with standardized mounting dimensions, allowing for straightforward installation in a variety of configurations. Its adaptable design ensures compatibility with common mounting setups, simplifying the installation process and reducing downtime.
In summary, the Lixin LW26 125A Cam Switch offers reliable performance and ease of installation, making it an ideal choice for controlling electrical circuits in diverse industrial and commercial applications.
